Praher K6 Series 1-Way Wafer Swing Check Valves

Praher K6 Series 1-Way Wafer Swing Check Valves

Available Now

Get in Touch

The K6 wafer check valve are made from uPVC material and are available with either EPDM or FPM seals. They are suitable for operating temperatures up to 60°C, max. 0.3 bar counterpressure. The conical sealing surface for highest of requirements and long service life. Back-flushed shaft for prevention of deposits. Cylindrically housed valve shaft for optimal force transmission. Screw centering for DIN2501 PN10 and ANSI class150. Integrated mounting aid with defined breaking point for simple removal. The K6 can be installed in the horizontal and vertical position.

Praher Plastics Austria GmbH (praher-plastics.com)
